Hashmi Sheets and Plates is a reputable manufacturer and supplier of Alloy Steel Gr 9 Sheets and Plates based in Doha, Qatar. They provide top-notch steel products designed for critical industrial and high-temperature applications. Known for their precision in manufacturing and strict quality control, the company adheres to international standards. Hashmi Sheets and Plates delivers Alloy Steel Gr 9 sheets and plates that boast a consistent composition, a superb surface finish, and dependable mechanical performance. They cater to various industries, including power generation, petrochemical, oil and gas, and heavy engineering, ensuring timely deliveries, competitive pricing, and technical support throughout Qatar and the Middle East for demanding structural and high-performance needs.
Alloy Steel Gr 9 Sheets and Plates mainly consist of chromium and molybdenum, along with a controlled carbon content in an iron base. The addition of chromium enhances resistance to corrosion and oxidation, while molybdenum boosts strength at high temperatures and improves creep resistance. In terms of mechanical properties, Gr 9 steel is known for its high tensile and yield strength, excellent toughness, good hardness, and reliable performance even under elevated temperatures. It also offers weldability and machinability, making it a great choice for pressure vessels, boilers, and high-temperature structural applications.
Alloy Steel Sheets and Plates Specification : ASTM A387 / ASME SA387
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
| BS | EN | ASTM/ASME | UNS | DIN |
|---|---|---|---|---|
| – | – | A387 / SA 387 | K90941 | – |
| C | Mn | P | S | Si | Cr | Mo |
|---|---|---|---|---|---|---|
| 0.15 max | 0.25 – 0.66 | 0.030 | 0.030 | 1.05 max | 7.9 – 10.1 | 0.85 1.15 |
| A387 / SA387 Grade 9 | Class 1 | Class 2 |
|---|---|---|
| Tensile Strength (ksi) | 60-85 | 75-100 |
| Tensile Strength (MPa) | 415-585 | 515-690 |
| Yield Strength (ksi) | 30 | 45 |
| Yield Strength (MPa) | 205 | 310 |
| Elongation in 50mm (%) | 18 | 18 |
| Reduction of area in % | 45 | 45 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hashmi Sheets and Plates based in Doha, Qatar, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Alloy Steel Gr 9 Sheets and Plates offer numerous advantages, making them ideal for demanding applications. They exhibit superior strength, hardness, and wear resistance, ensuring durability in harsh conditions. The alloy’s excellent resistance to corrosion and high-temperature stability makes it suitable for aerospace, automotive, and power generation industries. Additionally, Alloy Steel Gr 9 demonstrates exceptional weldability, allowing for easy fabrication and machining. Its high tensile strength and improved fatigue resistance enhance its performance in heavy-duty applications, providing a reliable solution for structural components and high-performance machinery.
Yes, we offer custom sizes for Alloy Steel Gr 9 Sheets and Plates to meet specific project needs. Our team at Hashmi Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
These Alloy Steel Gr 9 Sheets and Plates are commonly used in situations that demand high strength, corrosion resistance, and performance at elevated temperatures. Typical applications include boiler tubes, pressure vessels, heat exchangers, piping systems, and structural components in power plants and petrochemical facilities. They are also found in oil and gas equipment, chemical processing units, and heavy machinery. Thanks to their outstanding mechanical properties, thermal stability, and durability, Alloy Steel Gr 9 sheets and plates are perfect for high-temperature, high-stress industrial applications that require long-term reliability.
